Welcome to J.C.H Draughting Ltd

Specialists in the 3D modelling of structural and Architectural steelwork and connection design


Our Expertise

J.C.H Draughting Ltd is a leading specialist service provider to the construction industry, located in the North West of England. We are committed to driving innovation and excellence in 3D Steel Detailing, 3D Modelling, and Building Information Modelling (BIM), delivering cutting-edge solutions that enhance project efficiency and precision.

Advanced Software Utilisation

Utilises the latest in Tekla, Strucad, and AutoCAD to provide cutting-edge detailing and 3D modelling.

Comprehensive Detailing & Design Services

Offers a wide range of services including general arrangement drawings, connection designs, fabrication drawings, and CNC data output.

Fast Turnaround and Efficient Collaboration

Works closely with all project stakeholders to ensure quick job completion and effective problem-solving during design and tender stages.


What we do:

J.C.H Draughting Ltd provides advanced 2D and 3D steel detailing services for the commercial and industrial steel industries. Leveraging cutting-edge software like Tekla, Strucad, and AutoCAD, the company collaborates with fabricators, engineers, architects, and project managers to deliver high-quality, cost-effective projects. With a focus on fast turnarounds and efficient problem-solving, J.C.H Draughting excels in creating precise general arrangement drawings, connection designs, and comprehensive fabrication documents, ensuring projects run smoothly from design to execution.



Project Examples

Please see below a small selection of projects we have detailed over the years

Giving Back

JCH Draughting LTD have proudly supported Wigan Youth Zone over the past 10 years as Silver Patrons, this is our way of giving back to our local community, please get in touch if you would like more information on how you can get involved with such a great charity.
